CANIS GO 410 REVERSE

Our entry-level Canis GO 410 Reverse is as good as it gets. While it is lighter in weight than the original Canis work light, the operational lumens output is just as high. Best suited to construction, forestry, agriculture, and material handling, the Canis GO 410 Reverse has a round form factor and pedestal mounting, it produces zero emissions (EMC CISPR 25 class 5) and its light output is 1000 lumens

Not all products are available in all markets. During continuous improvement specifications and design are changing. All values are nominal values. Illustrations do not necessarily show the design of every version and some features are version specific. The lumens output varies depending on lens colour.

Key Features

  • Reverse light (ECE R23)
  • Operational lumens output: 1200lm
  • Pure performance in a compact design

Connectors


Built-in Deutsch DT-2 (2-pin)

Technical Data

Theoretical Lumens Output1900lm
Operational Lumens Output1200lm
Colour Temperature5000K
Nominal Voltage DC12 - 24V, 36 - 48V
Input Voltage DC9 - 16V, 18 - 32V, 30 - 64V
Power Consumption18W
Nominal Current at36-48V=0.38A, 24V=0.6A, 12V=1.1A
ConnectorBuilt-in Deutsch DT-2 (2-pin)
MountSingle Bolt M8
Shock60G
Vibration8Grms 24-2000Hz
LensPC
Body / HousingAluminum
Weight0.5kg
IP RatingIP68, IP6K9K
Salt Spray TestISO 9227 240H
EMCCISPR 25 Class 5, EN12895, ISO 13766, ISO 14982, ISO 7637-2, R10
Operating Temperatures-40°C... +85°C (Overheat protected)
ElectronicsIsiolated

Light Patterns

Click to zoom

Drawings

Click to zoom

Part Numbers

Reverse: 988-501B
